Öhlins DH38 m.1 Downhill Race Fork

Item #KSU11102
New with Warranty
Regular price


Your gear ships fast with Standard, Two-Day, or Local Pickup.

Canadian Customers

Please note that any duties, taxes, or surcharges as required by Canadian customs and provincial authorities will be the buyer's responsibility. Shipping to Canadian addresses may take longer than expected due to customs.

30-Day Returns

Every product we sell is covered by a hassle-free 30-day satisfaction guarantee.

More details More details icon
Why We Love It
Combine Ohlins' race-winning DH38 platform with a number of key upgrades and together they form the best downhill fork we’ve ever created – the DH38 m.1.

Whether you ride an e-MTB gravity rig or the pedal-powered version, with superb small bump tracking and the ability to soak up landings from even the heftiest drop-off, the DH38 m.1 fork will give you smoother, faster and more confident feeling runs than anything you’ve ridden before.

Redesigned seals work with Ohlins' new lubes and greases to further enhance the incredibly plush feel of the DH38 m.1. This actively boosts the levels of traction and control and helps smooth out even the most demanding course, enabling you to push your bike harder and finish your run feeling less fatigued.

The award-winning DH38 m.1 fork utilizes Ohlins' TTX twin-tubed damping system to deliver unrivalled control and flawless damping whatever the riding conditions. This new model comes packed with enhancements and upgrades over the original, resulting in the plushest feeling, most capable and most easily customizable DH fork on the market.

Just like every product fitted with TTX damping technology, the DH38 m.1 fork has a race-proven settings bank giving access to a huge range of options for tuning the damper to suit any specific rider, bike or riding style. The independent third air chamber allows you to adjust bottom out ramp with only a shock pump. No volume spacers or tokens needed.
About This Item
  • Fork crown set sold separately
  • New lubrications and functional greases decrease the breakaway force to make the fork feel smoother than ever before.
  • New low friction seal head design enables increased oil levels for further lubrication and an ultra-plush feel.
  • The size of the negative chamber can now be increased through tuning to further improve rider comfort, or to add spacers for additional feedback and control.
  • The DH38 m.1 utilises the pressurized piston design from the highly rated RXF36 m.2 ensuring an even more consistent damper performance.
  • A new needle design gives a greater degree of low-speed compression and rebound damping adjustment, enabling you to dial in your perfect set-up.
  • 3 chamber air spring allows for tool-free air volume tuning. No volume spacers or tokens needed.
  • TTX-technology
  • Independent cartridge spring and damper systems
  • Designed for use with a 200/203mm disc
  • Uses the 110x20 Boost DH hub standard
  • 38mm upper tube diameter for added strength
  • Various offsets available to suit your ride - 46/50/54/58 mm
  • Compatible maximum tire sizes 29 x 2.8 and 27.5 x 3.0
  • Dual-clamp floating axle for minimum friction
  • Available with 180 and 200mm stroke
  • E-bike approved
  • Race proven settings bank for easy and safe tuning
  • Weight : 2820g (200mm with crown)
Toggle accordion
Brand Ohlins
Model DH38 m.1 Downhill Race
Wheel Size 29"
Travel 180mm
Stanchion Size 38mm
Steerer Tube Diameter Tapered
Brake Mount Disc Brakes - Hydraulic
Weight 2820 grams
Front Axle Spacing 20x110mm (Thru-Axle/Boost)
